S-Band Circular Antenna

The AAC SpaceQuest developed AC-2000 nanosatellite polarized S-band antenna has been designed with high performance and ease of system integration in mind.

The AC-2000 is a turnstile circular polarized S-band antenna for micro satellite and small satellite. Its small size, low profile, rugged design, and high directionality make it an excellent addition to the system.

This robust design is ideal for applications where true circularity and low elevation angle performance is required. This flight proven commercially available solution covers a bandwidth of up to 300 MHz and is compatible with the nanosatellite standard.

With high gain, 2 dBi or 2 dBic, the AAC SpaceQuest developed AC-200 offers exceptional performance. The antenna also has a built-in ground plan and can include an optional protective cover.

While not CubeSat Standard, this solution can be used in a CubeSat system design.

Compatible

Our AC-2000 S-Band patch antenna can be easily incorporated into the CubeSat design and covers the entire S-Band frequency range of 2000 MHz to 2300
MHz.

Performance

With high gain of typically 5.2 dBic, the AAC SpaceQuest developed AC-2000 offers exceptional performance.

Reliability

The light and rugged design offers exceptional reliability. The flightproven antenna has a built-in ground plan and can include an optional protective cover.



Why the AC-2000?

  • 300 MHz Bandwidth (2000-2300 MHz)
  • 2 dB Gain with Integrated Ground Plan
  • Very Low Eccentricity
  • RH or LH Circular Polarization
  • Rugged Compact Design
  • SMA RF Output
  • Space Qualified

Technical Specifications

General Specifications
Bandwidth 300 MHz Bandwidth (2000 MHz to 2300 MHz)
VSWR 1.5 : 1.0
Peak Gain 5.2 dBic typical
Impedance 50 Ohms
Mass ~100 grams
Size Approximately 2” x 2” (Frequency Dependent)
Operating Temperature -40°C to +80°C (Storage Temperature: -50°C to +100°C)
Antenna Gain and Beam Pattern
S-BANDPhi
Point Theta 0 45 90
1 0.0 0.0 0.0 0.0
2 22.5 -1.0 -0.9 -0.5
3 45.0 -2.1 -3.1 -2.1
4 67.5 -3.4 -3.5 -6.0
5 90.0 -7.1 -5.0 -7.0
6 112.5 -11.3 -8.5 -8.3
7 135.0 -30 -30 -30
8 157.5 -30 -30 -30
9 180.0 -30 -30 -30
10 202.5 -30 -30 -30
11 225.0 -30 -30 -30
12 247.5 -12.8 -11.5 -14.5
13 270.0 -11.4 -11.0 -15.8
14 292.5 -5.0 -7.0 -7.8
15 315.0 -3.4 -3.5 -4.8
16 337.5 -1.0 -1.5 -1.6
