EPIC 3U

Our experience in the delivery of CubeSat missions for a wide range of applications means that our EPIC and EPIC PLUS platforms have the versatility to meet the requirements of the vast majority of payloads.

The EPIC 3U and EPIC 3U PLUS CubeSat range is our most popular spacecraft.  With many AAC Clyde Space 3U CubeSats produced and operating on orbit, this range of spacecraft arguably offers the best value to orbit of any satellites.  The combination of our commitment to quality design and build, flight proven performance, unrivalled operational up-time and excellent customer service means that our EPIC 3U range is the professional's choice for CubeSat missions that need to deliver.

Make an enquiry

Product Detail

EPIC 3U PLUS EPIC 3U
Payload Volume (min) 1.5 U 2 U
Peak Payload Power 120 W 60 W
Power Bus VBAT 3.3V, 5V and 12V VBAT 3.3V, 5V & 12V
Energy Storage (min) 80 Wh 40 Wh
Pointing (min) <0.1º
Stability 0.005º/s
Data Storage (min) 4 GB
Reliability EPIC-SAFE
Data Bus I2C, CAN, UART, QSPI, LVDS, RS232, RS422
Data Downlink 100Mbps/9.6Kbps 8Mbps/9.6Kbps
Frequency X/VHF/UHF S/VHF/UHF
Framing CCSDS Compatible CCSDS Compatible
Security AES256 Encryption Authentication AES256 Encryption, Authentication
Design Lifetime 5yr
